Ceres Neutron Counts Reflect Hydrogen Abundance

This map shows a portion of the northern hemisphere of Ceres with neutron counting data acquired by the gamma ray and neutron detector (GRaND) instrument aboard NASA's Dawn spacecraft.

These data reflect the concentration of hydrogen in the upper yard (or meter) of regolith, the loose surface material on Ceres. The color information is based on the number of neutrons detected per second by GRaND. Counts decrease with increasing hydrogen concentration. The color scale of the map is from blue (lowest neutron count) to red (highest neutron count).

Lower neutron counts near the pole suggest the presence of water ice within about a yard (meter) of the surface at high latitudes.

The GRaND data were acquired from Dawn's low-altitude mapping orbit (LAMO) at Ceres, a distance of 240 miles (385 kilometers) from the dwarf planet. The longitude is centered on Occator Crater.
